Project Description

Panel saw with 2 meters sliding beam;

Ideal machine for panels up to 2000mm width



ASK FOR PRICE
  • Panel saw wth 2 meters Sliding beam
  • Economic version of professional panel saw
  • Cast Iron Precision Ground Table
  • 2 meters travel sliding beam with 2000mm length of cutting
  • The beam can be locked in position when using the ripfence
  • Strong telescopic arm to take the weight of larger panels
Model W1-PS12-2
Blade Dia 315×30mm+90×20mm
Power: 3000W
Blade Speed: 4000rpm/main,5800rpm/small
Max.Cutting Height 100mm/90°-80mm/45°
Main Table Size: 800×385mm
Extension Table: 800×440×2+310×500mm
Sliding beam: 2000mm
Sliding Table Travel 2000mm
GW/NW: 295/250kg
Packing Size: 94×77×100cm+206×25×32cm
